Visualizing the benefits of diversification with Python

Have you been tempted to put all you money on one hyped up stock, get rich and quit your job? If your answer is yes, this article is for you.

Why is diversification a no-brainer?

We all (hopefully) know that smart diversification is an essential part of a good investment plan. However, when we see assets skyrocketing, it is tempting to want to put all you eggs in one basket.

Risk vs Reward Trade-off

Before we continue, bear in mind that I will be using the terms volatility, risk and standard deviation interchangeably. Note that in portfolio analysis, they mean the same thing.

  • Nukia’s expected return is a bit lower, at 15%. However, the risk is also lower, at 7%.
### characteristics of each asset
game_step = {'expected_return': 0.25, 'volatility': 0.15}
nukia = {'expected_return': 0.15, 'volatility': 0.07}
correlation = 0.3

Sharpe Ratio

Well, if you had to choose just one, a good way to decide is to look at Sharpe Ratio of each one. It is a benchmark measure of the most important trade-off in investments: risk vs return

Standard Deviation = Risk = Volatility

Portfolio Return

Let’s start off with the combined returns. It is very easy to calculate, since it will be the weighted average of the returns of GameStep and Nukia.

def calculate_portfolio_returns(weight_a, weight_b):
ret_a = weight_a * game_step['expected_return']
ret_b = weight_b * nukia['expected_return']
combined_return = ret_a + ret_b
return combined_return

Portfolio Risk

On the other hand, the portfolio volatility is not a simple weighted average. If you diversify, it will be lower than the simple weighed average as long as both assets are not perfectly correlated.

Let’s get technical

If you want to go deeper into it, here is the formula for the portfolio variance (feel free to skip to the next session if you prefer):

You don`t need to memorize it. The takeaway is that portfolio volatility is not a linear combination of the assets volatility.
# creates list of 21 diferent ratio combinations
allocation_strategies = [[w, 1-w] for w in np.linspace(0, 1, 21)]
# calculates the portfolio volatility
correlation = 0.3
def calculate_portfolio_vol(weight_a, weight_b, correlation):
vol_a = game_step['volatility']
vol_b = nukia['volatility']
portf_variance_formula = (
( weight_a**2 ) * (vol_a**2)
+ ( weight_b**2 ) * (vol_b**2 )
+ 2*correlation*weight_a*weight_b*vol_a*vol_b
)

portf_volatility = portf_variance_formula**(1/2)
return portf_volatility
# creates list of different allocation strategies
allocation_strategies = [[w, 1-w] for w in np.linspace(0, 1, 21)]
# calculates the portfolio return and volatility
# for each allocation strategy
import pandas as pd
def test_allocation(allocation_strategies, correlation):
d = {}
portfolio_returns = []
portfolio_volatility = []
for allocation in allocation_strategies:
weight_a = allocation[0]
weight_b = allocation[1]


combined_return = calculate_portfolio_returns(
weight_a,
weight_b)

portfolio_returns.append(combined_return)

combined_vol = calculate_portfolio_vol(
weight_a,
weight_b,
correlation)

portfolio_volatility.append(combined_vol)

d['returns'] = portfolio_returns
d['volatility'] = portfolio_volatility
return pd.DataFrame(d)
portfolios_df = test_allocation(allocation_strategies, correlation)## plots the figures# creates figure and subplots
fig, axs = plt.subplots(10, 10,
figsize=(10, 10),
sharex=True)
ax1 = plt.subplot2grid(shape=(10, 7),
loc=(0,0),
colspan=10,
rowspan=7)
ax3 = plt.subplot2grid(shape=(10, 3),
loc=(7,0),
colspan=10,
rowspan=3)
### plots the portfolio returns curve
color = 'tab:blue'
ax1.set_ylabel('Returns', color = color)
ax1.plot(alloc_labels,
portfolios_df['returns'],
color = color)
ax1.tick_params(axis ='y',
labelcolor = color)
ax1.tick_params(axis ='x',
labelcolor = 'white')

# Adding Twin Axes to plot portfolio volatility on the same subplot as ax1
ax2 = ax1.twinx()
### plots the portfolio returns curve
color = 'tab:green'
ax2.set_ylabel('Volatility',
color = color)
ax2.plot(alloc_labels,
portfolios_df['volatility'], color = color)
ax2.tick_params(axis ='y',
labelcolor = color)
# Adding title
plt.title('Risk/Return for different allocation strategies',
fontweight ="bold")
ax3.plot(alloc_labels,
portfolios_df['sharpe'],
color='gray',
label='Sharpe Ratio')
ax3.set_ylabel('Sharpe Ratio', color = 'black')
ax3.tick_params(axis ='y', labelcolor = 'black')
ax3.tick_params(axis ='x', labelcolor = 'gray', rotation=45,)
ax3.set_xlabel('allocation strategies')
plt.show()

Visualizing the Portfolio Curve

To get a better picture of how the portfolio performs for each allocation strategy, consider the chart below, that shows volatility (x-axis) and returns (y-axis):

the lower the correlation, the more “curved” it becomes
The lower the correlation, the higher the maximum Sharpe becomes.
# portfolio curve chart
plt.figure(figsize=(12, 7))
plt.plot(portfolios_df['volatility'],
portfolios_df['returns'], color='purple'
)
plt.title('Portfolio Curve', fontsize=20)
plt.xlabel('Volatility')
plt.ylabel('Return')
plt.scatter(nukia['volatility'], nukia['expected_return'], color='red')
plt.scatter(nukia['volatility'], 0.1665
, color='blue')
plt.show()# portfolio curves for different correlations
plt.figure(figsize=(12, 7))
for corr in np.linspace(0.1, 1, 10):
corr_df = test_allocation(allocation_strategies, corr)

plt.plot(corr_df['volatility'],
corr_df['returns'], label=round(corr, 1)
)
plt.title('Portfolio Curves for Different Correlation Levels', fontsize=20)
plt.xlabel('volatility')
plt.ylabel('return')
plt.legend()
plt.show()
# sharpe ratios for different correlations
plt.figure(figsize=(12, 7))
for corr in np.linspace(0.1, 1, 10):
corr_df = test_allocation(allocation_strategies, corr)

plt.plot(alloc_labels,
corr_df['sharpe'], label=round(corr, 1)
)
plt.title('Sharpe Ratio for Different Correlation Levels', fontsize=20)
plt.tick_params(axis='x', rotation=45)
plt.xlabel('allocation')
plt.ylabel('Sharpe Ratio')
plt.legend()
plt.show()
